GRG-4297u
GPON VoIP Gateway BE3600
GPON | Dual-Band Wi-Fi 7 | 2.5 Gigabit Ethernet | VoIP
-
Overview
Description:
Comtrend’s GRG-4297u is designed as a GPON ONT Gateway with capability to provide strong and stable wireless connectivity by its industrial leading Wi-Fi 7 configuration, Dual-Band (2.4GHz 2T2R, 5GHz 2T2R) GRG-4297u can fulfill most of demands for family use, with one GPON port as input of the internet source; one 2.5 Gigabit Ethernet port and three Gigabit Ethernet LAN, one RJ-11 VoIP ports and WiFi 7 BE3600
IEEE
StandardMax Data Rate Bands Bandwidth Modulation MIMO 802.11be 4G bps 2.4GHz, 5GHz up to 160 MHz 4096-QAM OFDMA 16 x 16 UL/DL
MU-MIMO
Features
KEY FEATURES
- Wi-Fi 7 (802.11BE): Dual-Band Wi-Fi 7, industrial leading Wi-Fi configuration.
- 2.5 Gigabit Ethernet LAN port: Capable to provide high-speed connectivity.
- MLO: As most current APs and Stations incorporate dual-band or tri-band capabilities.
- Remote Management: TR-069 / TR-181 standard data model for ISP remote control
Specifications
HARDWARE SPECIFICATIONS
Main CPU
- RTL9607F
Wi-Fi Chipset
- RTL8902A, RTL8932AR
Flash
- NAND Flash: 128M Byte
RAM
- (Embedded) 4G Bits
Interfaces
- GPON (SC/APC) x 1
2.5Gigabit Ethernet LAN x 1, Gigabit Ethernet LAN x 3
VoIP (FXS) x 1
LED Indicators
- Power, Internet, LOS, PON, USB, Phone 1, 2.5GE, GE1, GE2, GE3, 2.4G Wi-Fi, 5G Wi-Fi
Antenna
- Dual-Band Antenna x 2
Button
- Power Switch, Wi-Fi On/Off, WPS, Reset button, LED on/off
USB
- USB 2.0 x 1
Power Input
- 12DVC/2.5A, 100-240ACV, 50/60Hz
RF SPECIFICATIONS
Wireless Standard
- 802.11be/ax/ac/n/g/b/a
Frequency Band
- 2.4GHz, 5GHz
ADVANCED FEATURES
Wi-Fi Features
- 160MHz bandwidth, 4096-QAM, MLO, MUR
Wi-Fi Security
- WPA, WPA2, WPA3
Management Function
- TR-069 (TR-181, TR-369), HTTP, HTTPS, TELNET, SSH
ENVIRONMENT
Temperature
- Operating: 0°C ~ 40°C (32°F ~104°F)
- Storage: -40°C ~ 70°C (-40°F ~158°F)
Humidity (Non-condensing)
- Operating: 10 ~ 90% RH, non-condensing
- Storage: 5 ~ 90% RH, non-condensing
