GRG-4355u

XGS-PON WiFi 7 GW BE7200
2.4GHz & 5GHz 4x4 Concurrent | 10GE LAN | VoIP | USB

  • Overview

    Comtrend’s GRG-4355u is designed as an XGS-PON device. It offers high-performance Data, Voice and Video services for individual users, SOHO (small office or home office) setups, and small businesses, among others.

    It provides one high-speed 10GE LAN port and four GE ports, along with two FXS ports for internet calling. It also features dual-band Wi-Fi 7 (4T4R 802.11be@2.4GHz and 4T4R 802.11be@5GHz). The two wireless bands are separated into two dedicated Wi-Fi networks, which support more end-user devices while reducing signal interference. Furthermore, there is a USB 3.0 host interface on the user side.

    GRG-4355u GRG-4255u

    Features

    • Dual-band MLO in Wi-Fi 7: Simultaneous Multi- Link Operation on two frequency bands amplifies throughput, improves reliability, optimizes load balancing, and reduces latency by dynamically utilizing spectrum resources
    • OFDMA and MU-MIMO: Supports both up-link and down-link, allowing efficient data transmission for more devices at the same time
    • XGS-PON: 10G/10G UL/DL provides high speed fiber to the home services
    • 4x 10/100/1000BASE-T Ethernet LAN ports
    • 1x 10GE Ethernet LAN port
    • Supports Voice over Internet Protocol (VoIP) as a flexible and affordable solution for voice calls
    • 1x USB3.0
    • Remote Management: TR-069 standard data model for ISP remote control.

    Specifications

    Flash Memory

    • 512MB

    SDRAM

    • 512MB

    WAN(PON)

    • 1 x XGS-PON
      SC/APC
      Both downstream and upstream rates can reach 10Gbps

    10G LAN

    • 1x RJ-45 Port

    GE LAN

    • 4x RJ-45 Ports

    FXS (VoIP)

    • 2x RJ-11 Ports

    USB

    • 1x USB3.0

    Buttons

    • Power, WPS, Factory Reset

    LEDs

    • POWER / PON / LOS / NET / 2.4G/5G / lan1~4 / TEL1·2

    Features

    • WAN Type: IPoE / Static IP / PPPoE / Bridge
      Supports VLAN 1-4094
      Protocols: IPv4 / IPv6 dual stack
      Support IGMP Snooping & Proxy
      T.30/T.38/G.711 FAX mode
      Supports WAN/LAN access the Telnet & HTTP
      Supports Parental Controls
      Security: Firewall, IP/ MAC /URL Filter
      Supports TR-069 Remote Management Protocol
      Call waiting/ Unconditional Call Forward/Call Forward Busy/ Call Forward No
      Reply/ Three-party calls

    WiFi

    • 2.4GHz: 11be 4×4                 5GHz:11be 4×4
      2.4G Phy rate: 1376Mbps   5G Phy rate: 5764Mbps

    Power Adaptor

    • DC 12V/3A

    Dimensions

    • 190mm x 80mm x 255mm ( L x W x H)

    CERTIFICATIONS

    • CE & RoHS

    ENVIRONMENT

    • Operating Temperature: 0~ 45 degrees Celsius
    • Operating Humidity: 5 ~ 95%

    Resources

    Product Sheet

    DS_GRG4355u_V3.3.pdf
